Outrage
|
| #564 |
a 16' deep vee outboard ski
boat |
Build in PLYWOOD |
| Characteristics |
| Length overall |
16'-5" |
| Beam |
7'-0" |
| Hull depth |
26" |
| Average passengers |
1-4 |
| Hull weight (approx.) |
450 lbs. |
| Cockpit size |
5'-4" wide x 5'3" long |
- Hull type: Full length deep vee bottom with 12o deadrise, lift
strakes, and flaring topsides. Developed for sheet plywood planking.
- Power: Long shaft outboard motor to 125 hp.
- Can the hull be extended or shortened? Yes. Up to 10% by re-spacing the
frames from the aft end of the stem to the transom a proportional amount. We do
not recommend increasing the beam.
- Trailer: Designed for use with Glen-L Series 1700 boat trailer plans.
|
