Overniter
|
| #565 |
a 15' outboard
mini-cruiser |
Build in PLYWOOD |
| Characteristics |
| Length overall |
15'-11" |
| Beam |
6'-10" |
| Hull depth |
3'-6" |
| Average passengers |
1-3 |
| Hull weight (approx.) |
650 lbs. |
| Headroom under deck |
3'-0" |
| Sleeping accommodations |
2 |
- Hull type: Vee bottom hard chine hull developed for sheet plywood
planking.
- Power: Short shaft outboard motor to 100 hp. Long shaft motor can be used
if transom modified.
- Can the hull be extended or shortened? Extend: No. Shorten: Yes, up to 10%
by re-spacing the frames from the aft end of the stem to the transom a
proportional amount. We do not recommend increasing the beam.
- Trailer: Designed for use with Glen-L Series 1000 boat trailer plans.
|
