Fancy Free |
||
|---|---|---|
| #109 | a 21' gaff rigged sharpie | Build in PLYWOOD |
| Characteristics | |||
|---|---|---|---|
| Length overall (on deck) | 21'-3" | ||
| Length overall (including bowsprit) | 24'-2" | ||
| Waterline length | 19'-0" | ||
| Beam | 7'-6" | ||
| Freeboard forward | 3'-0" | ||
| Freeboard aft | 2'-1" | ||
| Draft (board up) | 8" | ||
| Draft (board down) | 3'-3" | ||
| Height (board up to cabin top) | 4'-3" | ||
| Displacement | 2500 lbs. | ||
| Ballast weight | 620 lbs. | ||
| Cabin headroom | 4'-0" | ||
| Cockpit well | 3'-3" x 2' fwd, 18" aft | ||
| Sleeping accommodations | 2 | ||
| Sail area |
Main - 130 sq. ft. Foretriangle - 100 sq. ft. Totals - 230 sq. ft. |
||
|
Hull type: Flat bottom hard chine dory, developed for
3/8" sheet plywood. Sail type: Gaff rigged sloop. Power: Outboard motor to 4 hp, 15" nominal shaft length, mounted in a well. Trailer: Designed for use with Glen-L Series 3800 boat trailer plans. |
|||
