Glen-L 21CB |
||
|---|---|---|
| #122 | a 21' centerboard sloop | Build in PLYWOOD |
| Characteristics | |||
|---|---|---|---|
| Length overall | 21'-3" | ||
| Waterline length | 19'-0" | ||
| Beam | 7'-9" | ||
| Freeboard forward | 2'-11" | ||
| Freeboard aft | 2'-2" | ||
| Draft (board up) | 10" | ||
| Draft (board down) | 4'-6" | ||
| Height (board up to cabin top) | 4'-10" | ||
| Displacement | 2000 lbs. | ||
| Hull weight (approx.) | 730 lbs. | ||
| Weight of centerboard | 400 lbs. | ||
| Cabin headroom (above berth) | 3'-0" | ||
| Cockpit size | 5'-6" x 6'-0" | ||
| Average passengers | 2-4 | ||
| Sleeping accommodations | 3 | ||
| Sail area |
Main - 93 sq. ft. Jib - 72 sq. ft. Genoa - 125 sq. ft. Totals - 165 or 218 sq. ft. |
||
|
Hull type: Vee bottom with steel centerboard, developed
for 3/8" sheet plywood. Sail type: Masthead centerboard sloop. Power: Outboard motor to 10 hp mounted on transom bracket (optional). Trailer: Designed for use with Glen-L Series 1700 boat trailer plans. |
|||
